Place of Origin:
CHINA
Brand Name:
QIEAL ZH
Model Number:
UCFC206
| Structure | Pillow block bearing |
| Brand name | WST |
| Quality standard | ISO9001:2008 |
| Services | OEM Based on your Aboriginal |
| Delivery time | 5-20 days |
| Bearing package | Roll ,box ,carton ,pallet |
| Payment term | L/C ,T/T |
| Material | Chromium steel (main), carbon steel, stainless steel, ceramic |
Pillow block bearing are particularly versatile. They are simple in design, non-separable, suitable for high and even very high speeds and are robust in operation, requiring little maintenance. Deep raceway grooves and the close conformity between the raceway grooves and the balls enable deep groove ball bearings to accommodate axial loads in both directions, in addition to radial loads, even at high speeds.
| Type | Dimensions (mm) | Weight | ||||||||||||
| d | a | p | and | l | S | k | g | f | FROM | With a | n | ds | (kg) | |
| UCFC201 | 12 | 100 | 78 | 55,1 | 25,5 | 12 | 7 | 20,5 | 62 | 28,3 | 31 | 12,7 | M10 | 0,78 |
| UCFC202 | 15 | 100 | 78 | 55,1 | 25,5 | 12 | 7 | 20,5 | 62 | 28,3 | 31 | 12,7 | M10 | 0,78 |
| UCFC203 | 17 | 100 | 78 | 55,1 | 25,5 | 12 | 7 | 20,5 | 62 | 28,3 | 31 | 12,7 | M10 | 0,78 |
| UCFC204 | 20 | 100 | 78 | 55,1 | 25,5 | 12 | 7 | 20,5 | 62 | 28,3 | 31 | 12,7 | M10 | 0,78 |
| UCFC205 | 25 | 115 | 90 | 63,6 | 27 | 12 | 7 | twenty one | 70 | 29,7 | 34 | 14,3 | M10 | 0,95 |
| UCFC206 | 30 | 125 | 100 | 70,7 | 31 | 12 | 8 | twenty three | 80 | 32,2 | 38,1 | 15,9 | M10 | 1,4 |
| UCFC207 | 35 | 135 | 110 | 77,8 | 34 | 14 | 9 | 26 | 90 | 36,4 | 42,9 | 17,5 | M12 | 1,7 |
| UCFC208 | 40 | 145 | 120 | 84,8 | 36 | 14 | 9 | 26 | 100 | 41,2 | 49,2 | 19 | M12 | 2 |
| UCFC209 | 45 | 160 | 132 | 93,3 | 38 | 16 | 14 | 26 | 105 | 40,2 | 49,2 | 19 | M14 | 2,8 |
| UCFC210 | 50 | 165 | 138 | 97,6 | 40 | 16 | 14 | 28 | 110 | 42,6 | 51,6 | 19 | M14 | 3 |
| UCFC211 | 55 | 185 | 150 | 106,1 | 43 | 19 | 15 | 31 | 125 | 46,4 | 55,6 | 22,2 | M16 | 4 |
| UCFC212 | 60 | 195 | 160 | 113,1 | 48 | 19 | 15 | 36 | 135 | 56,7 | 65,1 | 25,4 | M16 | 4,7 |
| UCFC213 | 65 | 205 | 170 | 120,2 | 50 | 19 | 15 | 36 | 145 | 55,7 | 65,1 | 25,4 | M16 | 5,4 |
| UCFC214 | 70 | 215 | 177 | 125,1 | 54 | 19 | 18 | 40 | 150 | 61,4 | 74,6 | 30,2 | M16 | 6,8 |
| UCFC215 | 75 | 220 | 184 | 130,1 | 56 | 19 | 18 | 40 | 160 | 62,5 | 77,8 | 33,3 | M16 | 7,3 |
| UCFC216 | 80 | 240 | 200 | 141,4 | 58 | twenty three | 18 | 42 | 170 | 67,3 | 82,6 | 33,3 | M20 | 8,9 |
| UCFC217 | 85 | 250 | 208 | 147,1 | 63 | twenty three | 20 | 45 | 180 | 69,6 | 85,7 | 34,1 | M20 | 10,4 |
| UCFC218 | 90 | 265 | 220 | 155,5 | 68 | twenty three | 20 | 50 | 190 | 78,3 | 96 | 39,7 | M20 | 13 |
Packing
1. Industrial packaging: plastic bag + kraft paper + carton or wooden ; plastic tube + carton
2. Commercial packing: 1pc/plastic bag + color box + carton
3. According to customs' requirements
Q: Are you trading company or manufacturer ?
A: We are a professional Trading company + factory in China .
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=8000USD, 100% in advance. Payment>=8000USD, 30% T/T in advance ,balance before shippment.
