Place of Origin:
CN
Brand Name:
ZH
Model Number:
Tapered roller bearings 33115
Double Row Tapered Roller Bearings 33115 For Excavator Machine size 75*125*37mm
Product Details
Dear my friend, our company has thousands of products, and we cannot display them all at the moment. If you need to leave a message or send an email to us, we will serve you as quickly as possible, thanks! ! !
Bearing number : 33115
Size (mm) : 75x125x37
Brand : ZH
Bore Diameter (mm) : 75
Outer Diameter (mm) : 125
Width (mm) : 37
Bearing dimensions and specifiexcavatorion in FAG excavatoralogue:
d - 75 mm
D - 125 mm
T - 37 mm
a - 30 mm
B - 37 mm
C - 29 mm
Ca min - 6 mm
Cb min - 8 mm
Da max - 116 mm
Da min - 109 mm
Db min - 120 mm
d1 - 101,4 mm
da max - 84 mm
db min - 84 mm
r1, 2 min - 2 mm
r3, 4 min - 1,5 mm
ra max - 2 mm
rb max - 1,5 mm
m - 1,79 kg / Weight
Cr - 178000 N
C0r - 275000 N / Static load rating (radial)
e - 0,4
Y - 1,51
Y0 - 0,83
Cur - 34500 N / Fatigue limit load, radial
nG - 5400 1/min / Limiting speed
nB - 3300 1/min / Reference speed
Mode of transport ...
within 3 days after received the payment , by air or by express or by sea on the basis of the
quantity and emergency circumstances.
