Place of Origin:
CN
Brand Name:
ZH
Model Number:
30318 Timken Tapered Roller Bearing 90x190x46.5mm
30318 ZH Taper Bearing , Precision Tapered Roller Bearings 90x190x46.5mm
Product Details
Dear my friend, our company has thousands of products, and we cannot display them all at the moment. If you need to leave a message or send an email to us, we will serve you as quickly as possible, thanks! ! !
Specifiexcavatorions
Series: 30318M
Cone part number: X30318M
Cup part number: Y30318M
Bearing weight: 5.56 Kg
Dimensions
d - Bore: 90.000 mm
D - Cup outer diameter: 190.000 mm
B - Cone width: 43.000 mm
C - Cup width: 36.000 mm
T - Bearing width: 46.5 mm
Basic load ratings
C90 - Dynamic Radial Rating (90 million revolutions)4: 105000 N / 23700 lbf
C1 - Dynamic Radial Rating (1 million revolutions)5: 406000 N / 91300 lbf
C0 - Static Radial Rating: 429000 N / 96500 lbf
Ca90 - Dynamic Thrust Rating (90 million revolutions)6: 62200 N / 14000 lbf
Mode of transport ...
within 3 days after received the payment , by air or by express or by sea on the basis of the
quantity and emergency circumstances.
