Place of Origin:
CHINA
Brand Name:
CNZH
Model Number:
23026
| inner diameter | 130mm |
| out diameter | 200mm |
| thickness | 52mm |
| unit weight | 6.2kgs |
| cage introduction |
steel cage: CC , E , E1 , CCJA, EA , CJ , EJ, BD1,CD brass cage: CA, MA , MB,YM, YMB, BL1 vibration use: CCJA , MA , MB CC, E, E1: two window type steel cage, guide ring centred on the inner ring or the cage CCJA: two window type steel cage , guide ring centred on the outer ring CA: one piece machined cage of brass, guide ring centred on the inner ring MA, MB :solid brass cage , guide ring centred on the outer/inner ring . |
| relative models |
23026CCW33 23026BD1 23026CDE4 23026CAW33 23026-E 23026-E1 23026EA 23026MA 23026MB 23026CCJAW33 23026CCC3W33 23026CAC3W33 23026CCK/W33 23026CAK/W33 23026MBK 23026-EK 23026-E1K 23026BMB 23026MA |
| using area |
Widely used in Industries such as Metallurgy, Rolling Mills, Mining, Petroleum, Papermaking, Cement, Sugar extraction, etc. |
| cover market |
BRAZIL , CHILE ,PERU , MEXICO, SPAN, SOUTH AFRICA, TURKEY VIETNAM , INDONESIA, THAILAND and ECT |
| 22300series | ||
| Bearing Number | Dimension (mm ) | Weight (kg) |
| 22306 | 30X72X19 | 0.37 |
| 22307 | 35X80X31 | 0.75 |
| 22308 | 40X90X33 | 1.03 |
| 22309 | 45X90X33 | 1.4 |
| 22310 | 50X110X40 | 1.85 |
| 22311 | 55X120X43 | 2.42 |
| 22312 | 60X130X46 | 3 |
| 22313 | 65X140X48 | 3.65 |
| 22314 | 70X150X51 | 4.4 |
| 22315 | 75X160X55 | 5.47 |
| 22316 | 80X170X58 | 6.63 |
| 22317 | 85X180X60 | 7.07 |
| 22318 | 90X190X64 | 8.76 |
| 22319 | 95X200X67 | 9.93 |
| 22320 | 100X215X73 | 13.7 |
| 22322 | 110X240X80 | 17.7 |
| 22324 | 120X260X86 | 22.9 |
| 22326 | 130X280X93 | 28.5 |
| 22328 | 140X300X102 | 35.5 |
| 22330 | 150X320X108 | 42 |
| 22332 | 160X340X114 | 52.2 |
| 22334 | 170X360X120 | 60.7 |
| 22336 | 180X380X126 | 72.6 |
| 22338 | 190X400X132 | 84.2 |
| 22340 | 200X420X138 | 94.4 |
| 22344 | 220X460X145 | 119 |
