Place of Origin:
China
Brand Name:
ZH
Certification:
IS09001
Model Number:
NJ206ET2X
NJ206ET2X 206ET2X NJ206 NJ206ET2XRS P0 P3 P2 P1 P5 P6 P4 Quality LEVEL CHROME STEEL Cylinder Roller Bearing
Product introduction
NJ206ET2X Roller Bearings are essentially wheel bearings with a cage. They have an inner ring, two integral flanges, and a fully removable outer ring. Any axial displacement of the shaft with respect to the housing can be accommodated in both directions; this bearing features both a reinforced structure, a brass solid retainer, and surface-finished roller ends. Roller Bearings are capable of accommodating heavy radial loads at high speeds, which makes them well suited for applications like conveyors and fans
| PRODUCT DEFINITION | |
|---|---|
| Brand | NTN |
| d - Internal diameter | 30 mm |
| D - External diameter | 62 mm |
| B - Bearing/Inner ring width | 16 mm |
| E - Upper roller diameter | 55,5 mm |
| F - Under roller diameter | 37,5 mm |
| d1 - IR flange outer diameter | 41,1 mm |
| rs - Min fillet radius | 1 mm |
| r1s - Min fillet radius | 0,6 mm |
| Radial clearance class | CN |
| Mass | 0,208 kg |
| PRODUCT PERFORMANCE | |
|---|---|
| C - Dynamic load | 46 kN |
| C0 - Static load | 37,5 kN |
| Cu - Fatigue limit load | 4,55 kN |
| Nlim - Oil lubrication limit speed | 15600 tr/min |
| Nlim - Grease lubrication limit speed | 11000 tr/min |
| Tmin - Min operating temperature | -20 °C |
| Tmax - Max operating temperature | 120 °C |
| ABUTMENT | |
|---|---|
| da min - Min shoulder diameter IR | 34 mm |
| da max - Small face shoulder max diameter | 37 mm |
| dc min - Min inner ring GO diameter | 44 mm |
| Da max - Max shoulder diameter OR | 57 mm |
| ra max - Max fillet radius | 1 mm |
| r1a - Max fillet radius | 0,6 mm |
