Place of Origin:
China
Brand Name:
Z&H
Model Number:
67390-67322
| Products Name | Tapered roller bearing made in China high quality |
| Size | 133.35*196.85*38.1 MM |
| Brand | Z&H |
| Type | Single-row taper roller bearing,Double-row taper roller bearing,Four-row taper roller bearing,auto bearing,Machine-tool bearing,Construction bearing ,Heavy-duty bearing ,tapered roller bearing ,agriculture machine bearing. |
| bearing material | bearing steel Gcr15 |
| Cage Material | Steel ,Brass |
| High speed performance | Good |
| Quality Standard | ISO9001:2000 |
| Service | OEM service |
| Payment Term | T/T,L/C |
| Appliexcavatorion widely | Widely used in general machinery, automobiles, agricultural machinery and so on |
| Packaging | single bag+single box+carton/according to your requestion |
| Market | Europe,America,Middle East,Asia,etc |
| Designation | Principal dimensions | Basic load ratings | Speed ratings | ||||
| dynamic | static | Reference speed | Limiting speed | ||||
| d | D | T | C | C0 | |||
| - | mm | kN | r/min | ||||
| 30319 | 95 | 200 | 50 | 330 | 390 | 2600 | 3400 |
| 33220 | 100 | 180 | 63 | 429 | 655 | 2400 | 3600 |
| 33022 | 110 | 170 | 47 | 281 | 500 | 2600 | 3600 |
| 33122 | 110 | 180 | 56 | 369 | 630 | 2600 | 3400 |
| 32322 | 110 | 240 | 85 | 627 | 830 | 1900 | 2800 |
| 32924 | 120 | 165 | 29 | 165 | 305 | 2600 | 3800 |
| 33024 | 120 | 180 | 48 | 292 | 540 | 2600 | 3400 |
| 32926 | 130 | 180 | 32 | 198 | 365 | 2400 | 3600 |
| 32928 | 140 | 190 | 32 | 205 | 390 | 2200 | 3400 |
| 33030 | 150 | 225 | 59 | 457 | 865 | 2000 | 2600 |
| 30230 | 150 | 270 | 49 | 429 | 560 | 1800 | 2400 |
| 32934 | 170 | 230 | 38 | 286 | 585 | 1900 | 2800 |
| 32936 | 180 | 250 | 45 | 352 | 735 | 1700 | 2600 |
| 32938 | 190 | 260 | 45 | 358 | 765 | 1600 | 2400 |
| 32940 | 200 | 280 | 51 | 473 | 950 | 1500 | 2200 |
| 32944 | 220 | 300 | 51 | 484 | 1000 | 1400 | 2000 |
| 32948 | 240 | 320 | 51 | 512 | 1080 | 1300 | 1900 |
| 32960 | 300 | 420 | 76 | 1050 | 2240 | 950 | 1400 |
| 32964 | 320 | 440 | 76 | 1080 | 2360 | 900 | 1300 |
| 332303 | 320 | 620 | 141 | 2810 | 4650 | 700 | 1000 |
| 32968 | 340 | 460 | 76 | 1080 | 2400 | 850 | 1300 |
| 32972 | 360 | 480 | 76 | 1120 | 2550 | 800 | 1200 |
| 332302 | 360 | 680 | 165 | 3690 | 6300 | 630 | 900 |
| 30302J2 | 15 | 42 | 14.25 | 22.4 | 20 | 13000 | 18000 |
| 30203J2 | 17 | 40 | 13.25 | 19 | 18.6 | 13000 | 18000 |
| 30303J2 | 17 | 47 | 15.25 | 28.1 | 25 | 12000 | 16000 |
| 32303J2/Q | 17 | 47 | 20.25 | 34.7 | 33.5 | 11000 | 16000 |
| 32004X/Q | 20 | 42 | 15 | 24.2 | 27 | 12000 | 16000 |
| 30204J2/Q | 20 | 47 | 15.25 | 27.5 | 28 | 11000 | 15000 |
| 30304J2/Q | 20 | 52 | 16.25 | 34.1 | 32.5 | 11000 | 14000 |
| 32304J2/Q | 20 | 52 | 22.25 | 44 | 45.5 | 10000 | 14000 |
| 320/22X | 22 | 44 | 15 | 25.1 | 29 | 11000 | 15000 |
| 32005X/Q | 25 | 47 | 15 | 27 | 32.5 | 11000 | 14000 |
| 30205J2/Q | 25 | 52 | 16.25 | 30.8 | 33.5 | 10000 | 13000 |
| 32205BJ2/Q | 25 | 52 | 19.25 | 35.8 | 44 | 9500 | 13000 |
| 33205/Q | 25 | 52 | 22 | 47.3 | 56 | 10000 | 13000 |
| 30305J2/Q | 25 | 62 | 18.25 | 44.6 | 43 | 9000 | 12000 |
| 31305J2 | 25 | 62 | 18.25 | 38 | 40 | 7500 | 11000 |
| 32305J2 | 25 | 62 | 25.25 | 60.5 | 63 | 8000 | 12000 |
| 320/28X/Q | 28 | 52 | 16 | 31.9 | 38 | 10000 | 13000 |
| 302/28J2 | 28 | 58 | 17.25 | 38 | 41.5 | 9000 | 12000 |
| 322/28BJ2/Q | 28 | 58 | 20.25 | 41.8 | 50 | 8500 | 12000 |
| 32006X/Q | 30 | 55 | 17 | 35.8 | 44 | 9000 | 12000 |
| 30206J2/Q | 30 | 62 | 17.25 | 40.2 | 44 | 8500 | 11000 |
| 32206BJ2/QCL7CVA606 | 30 | 62 | 21.25 | 49.5 | 58.5 | 8000 | 11000 |
| 32206J2/Q | 30 | 62 | 21.25 | 50.1 | 57 | 8500 | 11000 |
| 33206/Q | 30 | 62 | 25 | 64.4 | 76.5 | 7500 | 11000 |
| 30306J2/Q | 30 | 72 | 20.75 | 56.1 | 56 | 7500 | 10000 |
| 31306J2/Q | 30 | 72 | 20.75 | 47.3 | 50 | 6700 | 9500 |
| 32306J2/Q | 30 | 72 | 28.75 | 76.5 | 85 | 7000 | 10000 |
| JL26749F/710 | 32 | 53 | 14.5 | 27 | 35.5 | 9000 | 12000 |
| 320/32X/Q | 32 | 58 | 17 | 36.9 | 46.5 | 8500 | 11000 |
| 32007J2/Q | 35 | 62 | 18 | 37.4 | 49 | 8000 | 11000 |
| 32007X/Q | 35 | 62 | 18 | 42.9 | 54 | 8500 | 11000 |
| 30207J2/Q | 35 | 72 | 18.25 | 51.2 | 56 | 7000 | 9500 |
| 32207J2/Q | 35 | 72 | 24.25 | 66 | 78 | 7000 | 9500 |
| 33207/Q | 35 | 72 | 28 | 84.2 | 106 | 6300 | 9500 |
| 30307J2/Q | 35 | 80 | 22.75 | 72.1 | 73.5 | 6700 | 9000 |
| 31307J2/Q | 35 | 80 | 22.75 | 61.6 | 67 | 6000 | 8500 |
| 32307BJ2/Q | 35 | 80 | 32.75 | 93.5 | 114 | 6000 | 8500 |
| 32307J2/Q | 35 | 80 | 32.75 | 95.2 | 106 | 6300 | 9000 |
| 32307/37BJ2/Q | 37 | 80 | 32.75 | 93.5 | 114 | 6000 | 8500 |
| JL69345F/310/Q | 38 | 63 | 17 | 36.9 | 52 | 7500 | 11000 |
| JL69349A/310/Q | 38 | 63 | 17 | 36.9 | 52 | 7500 | 11000 |
| JL69349X/310/Q | 38 | 63 | 17 | 36.9 | 52 | 7500 | 11000 |
| JL69349/310/Q | 38 | 63 | 17 | 36.9 | 52 | 7500 | 11000 |
| 32008/38X/Q | 38 | 68 | 19 | 52.8 | 71 | 7000 | 9500 |
| 3490/3420/QCL7CVQ492 | 38.1 | 79 | 29.37 | 91.3 | 110 | 6700 | 9500 |
| 32008X/Q | 40 | 68 | 19 | 52.8 | 71 | 7000 | 9500 |
| 32008XTN9/Q | 40 | 68 | 19 | 52.8 | 71 | 7000 | 9500 |
| 33108/Q | 40 | 75 | 26 | 79.2 | 104 | 6700 | 9000 |
| 30208J2/Q | 40 | 80 | 19.75 | 61.6 | 68 | 6300 | 8500 |
| 32208J2/Q | 40 | 80 | 24.75 | 74.8 | 86.5 | 6300 | 8500 |
| 33208/QCL7C | 40 | 80 | 32 | 105 | 132 | 5600 | 8500 |
| T2EE040/QVB134 | 40 | 85 | 33 | 121 | 150 | 6000 | 9000 |
| 30308J2/Q | 40 | 90 | 25.25 | 85.8 | 95 | 6000 | 8000 |
1 . Single box packing, then in carton then in Pallet .
2 . Standard export packing .
3 . According customer demand .
1.you need to pay in advance
2.You can use west union
3.L/C at sight
4.30% T/T in advance . 70% against copy of B/L
1.Cylindrical roller bearing
2.Thrust ball bearing
3.Thrust roller bearing
4.Tapered roller bearing
5.Spherical roller bearing
6.Self-aligning ball bearing
7.Angular contact ball bearing
8.Joint bearing
Send your inquiry directly to us
