Place of Origin:
China
Brand Name:
Z&H
Model Number:
LR5002-2RS LR 5002 NPPU
video
LR5002-2RS LR 5002 NPPU Track Rollers Bearings Size 15x35x13mm
Products Description
| Bearing Name | 15x35x13mm Track Roller Bearing |
| Brand | Z&H |
| Model number | lr5002 |
| Material | Chrome Steel/GCr15 |
| Number of row | Single Row |
| Precision | P0 P6 P5 P4 P2 |
| STOCK | Great Supplying Ability |
| Warranty | 50000km or One year |
| Precision rating | ABCE-1 ABCE-3 ABCE-5 ABCE-7 |
| Vibration | V1 V2 V3 V4 |
| Clearance | C0 C2 C3 C4 C5 |
| Delivery Detail | 2-5 days upon receipt of deposit or according to your requirements |
| Shipping | Express ,AIR ,Sea Shipping |
| Type | Weight | D | d | B | C | Cw | Cow | Puw | Seal | Shield |
| (g) | mm | N | ||||||||
| LR5200 NPP | 70 | 32 | 10 | 14 | 14 | 6800 | 4050 | 168 | 8000 | 11000 |
| LR5200 NPPU | 70 | 32 | 10 | 14 | 14 | 6800 | 4050 | 168 | 8000 | 11000 |
| LR5200 KDD | 70 | 32 | 10 | 14 | 14 | 6800 | 4050 | 168 | 8000 | 11000 |
| LR5200 KDDU | 70 | 32 | 10 | 14 | 14 | 6800 | 4050 | 168 | 8000 | 11000 |
| LR5201 NPP | 80 | 35 | 12 | 15.9 | 16 | 8600 | 5100 | 211 | 7500 | 10000 |
| LR5201 NPPU | 80 | 35 | 12 | 15.9 | 16 | 8600 | 5100 | 211 | 7500 | 10000 |
| LR5201 KDD | 80 | 35 | 12 | 15.9 | 16 | 8600 | 5100 | 211 | 7500 | 10000 |
| LR5201 KDDU | 80 | 35 | 12 | 15.9 | 16 | 8600 | 5100 | 211 | 7500 | 10000 |
| LR5202 NPP | 110 | 40 | 15 | 15.9 | 16 | 9800 | 6200 | 258 | 7000 | 10000 |
| LR5202 NPPU | 110 | 40 | 15 | 15.9 | 16 | 9800 | 6200 | 258 | 7000 | 10000 |
| LR5202 KDD | 110 | 40 | 15 | 15.9 | 16 | 9800 | 6200 | 258 | 7000 | 10000 |
| LR5202 KDDU | 110 | 40 | 15 | 15.9 | 16 | 9800 | 6200 | 258 | 7000 | 10000 |
| LR5203 NPP | 170 | 47 | 17 | 17.5 | 18 | 12600 | 8200 | 342 | 5500 | 7500 |
| LR5203 NPPU | 170 | 47 | 17 | 17.5 | 18 | 12600 | 8200 | 342 | 5500 | 7500 |
| LR5203 KDD | 170 | 47 | 17 | 17.5 | 18 | 12600 | 8200 | 342 | 5500 | 7500 |
| LR5203 KDDU | 170 | 47 | 17 | 17.5 | 18 | 12600 | 8200 | 342 | 5500 | 7500 |
| LR5204 NPP | 230 | 52 | 20 | 20.6 | 21 | 15800 | 10500 | 433 | 5000 | 7000 |
| LR5204 NPPU | 230 | 52 | 20 | 20.6 | 21 | 15800 | 10500 | 433 | 5000 | 7000 |
| LR5204 KDD | 230 | 52 | 20 | 20.6 | 21 | 15800 | 10500 | 433 | 5000 | 7000 |
| LR5204 KDDU | 230 | 52 | 20 | 20.6 | 21 | 15800 | 10500 | 433 | 5000 | 7000 |
| LR5205 NPP | 340 | 62 | 25 | 20.6 | 21 | 18500 | 13000 | 532 | 4500 | 6500 |
| LR5205 NPPU | 340 | 62 | 25 | 20.6 | 21 | 18500 | 13000 | 532 | 4500 | 6500 |
| LR5205 KDD | 340 | 62 | 25 | 20.6 | 21 | 18500 | 13000 | 532 | 4500 | 6500 |
| LR5205 KDDU | 340 | 62 | 25 | 20.6 | 21 | 18500 | 13000 | 532 | 4500 | 6500 |
| LR5206 NPP | 510 | 72 | 30 | 23.8 | 24 | 24600 | 21400 | 880 | 3500 | 5000 |
| LR5206 NPPU | 510 | 72 | 30 | 23.8 | 24 | 24600 | 21400 | 880 | 3500 | 5000 |
| LR5206 KDD | 510 | 72 | 30 | 23.8 | 24 | 24600 | 21400 | 880 | 3500 | 5000 |
| LR5206 KDDU | 510 | 72 | 30 | 23.8 | 24 | 24600 | 21400 | 880 | 3500 | 5000 |
| LR5207 NPP | 660 | 80 | 35 | 27 | 27 | 30500 | 22400 | 927 | 2800 | 3900 |
| LR5207 NPPU | 660 | 80 | 35 | 27 | 27 | 30500 | 22400 | 927 | 2800 | 3900 |
| LR5207 KDD | 660 | 80 | 35 | 27 | 27 | 30500 | 22400 | 927 | 2800 | 3900 |
| LR5207 KDDU | 660 | 80 | 35 | 27 | 27 | 30500 | 22400 | 927 | 2800 | 3900 |
| LR5208 NPP | 750 | 85 | 40 | 30.2 | 30 | 34500 | 25500 | 1060 | 2500 | 3500 |
| LR5208 NPPU | 750 | 85 | 40 | 30.2 | 30 | 34500 | 25500 | 1060 | 2500 | 3500 |
| LR5208 KDD | 750 | 85 | 40 | 30.2 | 30 | 34500 | 25500 | 1060 | 2500 | 3500 |
| LR5208 KDDU | 750 | 85 | 40 | 30.2 | 30 | 34500 | 25500 | 1060 | 2500 | 3500 |
FAQ
1. Q: Are you a factory or trading company?
A: We are factory.
2. Q: Where is your factory loexcavatored? How can I visit there?
A: Our factory is loexcavatored in Shandong City, China. You can fly to Jinan Airport directly. All our clients, from home or abroad, are warmly welcome to visit us.
3. Q: How can I get some samples?
A: We are honored to offer you samples for your checking.
